PH50F038
Piezohannas
PH50F038
50KHz arduino ultrasonic sensor
 ultrasonic distance sensor circuit |  ultrasonic range finder sensor | ![%S5Z]JV%]E]$_@$Q$TP5J](http://5krorwxhlkpmrik.leadongcdn.com/cloud/ipBqnKjlRikSokqqqjio/S5Z-JV-E-_.png) outdoor ultrasonic distance sensor |
Introduction:
PH50F038 ultrasonic sensor has the functions of transmitter and receiver. It’s a long range type, generally can be used for ultrasonic range finder, ultrasonic sensor for non-contact detect objects, ultrasonic distance sensor, ultrasonic liquid level sensor, etc. If you have any questions for other applications, please contact us for details.
Technical parameters：
Model | PH50F038 |
Center resonant frequency (kHz) | 50KHz±2.0Khz |
Bandwidth | 4.0Khz |
Detection distance | 0.3~8m |
Blind spots | <0.3m |
Launch angle beam (-6dB full angle) | 14±2° |
Sensitive | -78dB min |
Electrostatic capacitance | 2000PF±20% |
Minimum parallel impedance | 250Ω±30% |
Maximum working voltage (Pulse - 2% duty cycle) | 1000Vp-p |
Operating temperature | -20 ~70℃ |
Storage temperature | -40 ~85℃ |
Protection level | IP65 |
Size (diameter * height, mm) | Φ50x65 |
Installation | Fixed with screw |
Case Material | ABS or Aluminum alloy shell |
Cable length | 2M (can be customized) |
Weight | 200g |
Photo:
Outline Dimension：
Test Circuit：
Features of ultrasonic sensors:
1.Small size and light-weight
2. High sensitivity and high sound pressure
3.Low power consumption
4.High reliability
Characteristic:
Solid package (ABS or Aluminum alloy shell)
Installation expediently (M20*1.5 Screw)
Application:
1.Position Location
2.Approach measurement
3.Traffic Measurement
4.Avoiding Obstacles
