low cost foam shore hardness test meter price

Share to:

low cost foam shore hardness test meter price

Name: low cost foam shore hardness test meter price
Brand: Piezohannas
Rating: 5.0 (17 reviews)

Applications：
Memory Foam Hardness Tester PH-MF0156 , special for memory foam hardness measurement.(memory foam is also known as slow rebound sponge, space zero pressure, space cotton,TEMPUR material, low rebound sponge material, viscoelasticity, used in high velocity space, aviation, equipment, high-end consumer goods.)

Availability:

Model:
PH-MF0156
Brand:
Piezohannas
Code:
PH-MF0156

Product Description

Hardness Tester Manufacturers

WuHan Piezohannas Tech.Co .,Ltd is a manufactuer of piezoelectric ceramics ,ultrasonic transducers and some other ultrasonic deivce with strong technology force.With a quality management system and research & development sector,our products are extensively used in most applications.

$RW_0D_(CV8_LT3%]M$2Z{@0.png$

hardness tester price

shore foam durometer tester

cheap metal shore hardness test for aluminum.jpg

shore durometer meter

Features:

* Specially for hardness testing of MEMORY FOAM.

* It meets standards of DIN 53505, ISO 868, ISO 7619, ASTMD 2240, JISK7215.

* With average calculate function.

* Peak value deposit function.

* Under-voltage alarm function.

* Use “USB data output” and “RS-232 data output” to connect with PC.

* Provide “Bluetooth ™ data output” choice.

Specifications:

Parameters	Tested Result/Mean Value/Max.Value
Display Range	0~100HMF
Measurement Range	10~90HMF
Resolution	0.1HMF
Accuracy	<<±1HMF
Spring Force	455gf
Sensor Head Diameter	25mm
Sensor Foot Diamter	80mm
Battery Indicator	Low Battery Indicator
Auto Switch Off	√
Operating Conditions	Temp:0~40ºC Humidity:10~90%RH
Power Supply	4x1.5V AAA Size(UM-4)Battery
Dimensions	162x80x80mm(6.4x3.1x3.1 inch)
Weight	250g
Standard	Main Unit
Accessories	Carrying Case(B04)
Accessories	Operation Manual
Optional Accessories	USB Data Cable with Software
Optional Accessories	Bluetooth Data Adapter with Software

Standard Accessories:

1. Main Unit

2. Carrying Case

3. Operation Manual

Optional Accessories:

1. USB, RS-232C data cable with software

2. Bluetooth data out put with software

shore foam durometer tester foam shore hardness for soft materials low cost shore durometer meter foam hardness measurement price digital hardness test price shore durometer gauge of foam foam shore a durometer tester shore hardness of foam hardness tester price low cost foam hardness tester
