Think You're An Expert In Piezoelectric Ceramic Sensor

Views:3     Author:Site Editor     Publish Time: 2018-02-04      Origin:Site

Think You're An Expert In Piezoelectric Ceramic Sensor

                        Think You're An Expert In Piezoelectric Ceramic Sensor


Polarization conditions is on the piezoelectric properties of porous PZT ceramic membrane.Porcelain PZT ceramic is obtained by calcining 950℃ polarization, the oil bath temperature of pzt piezoelectric actuators was adjusted to 100,120,140 ℃, the polarization electric field strength of pickup piezo transducer is 2,3,4,5 kV·mm-1, according to the literature, selecting the polarization time is 1 h. The device shown was tested for the piezoelectric properties of the porous PZT ceramic membrane after polarization. The effects of temperature and voltage on the piezoelectric properties of porous PZT ceramic films were investigated.Piezo rings level sensor can be seen that increasing the temperature of the oil bath and increasing the polarization voltage can enhance the polarization effect of the PZT ceramic film. However, increasing the temperature of piezoelectric transducer datasheetdecreases the breakdown voltage of the PZT ceramic film and reduces the upper limit of the DC voltage used for polarization. The difference in the electrical piezo ceramic with resonance frequency between samples is caused by the deviation of the individual thickness of the sample from the pore micro structure. Considering the influence of temperature and voltage on the polarization effect, the PZT ceramic membrane obtained when the temperature of the piezo knock sensor is controlled to 120 ℃ and the polarization electric field intensity has good piezoelectric properties. At this time, when the output voltage of the signal transmitter is 20 V and the frequency is 231 kHz, the detected resonant frequency of the PZT ceramic film is 231 kHz and the electrical signal value is 44.8 mV.
