PH80233
Piezohannas
PH80233
1.Spesifikasi:
Saiz taip |
Prestasi P arameter s |
kitaUsia |
||
Jenis lain |
Jenis tong lurus |
Kapasiti elektrik statik ( Pf ) |
8000 |
ikatan ultrasonik |
Q uatiti cip |
4 |
Kekerapan resonans ( kHz ) |
14.90 |
|
15.00 |
||||
Saiz cip ( mm ) |
Ø 60×Ø 30×10 |
KHz lebar |
1.30 |
|
0.20 |
||||
L diameter terbesar ( mm ) |
Ø61 |
Impedans 9Ω ) |
≤ 10Ω |
|
Ø 80×233 |
≤ 15Ω |
|||
Tinggi (mm ) |
151 |
Impedans penebat （ Ω ） |
≥ 100M Ω |
|
Masukkan dan ubah menjadi tiang |
||||
Puting sumber |
M20×1.5 |
Kuasa （ W ） |
2100 |
|
Berikut adalah beberapa saiz biasa untuk transduser seramik piezoelektrik untuk kimpalan.
taip |
Dimensi (mm) |
Kekerapan |
Kapasitansi |
Impedans(Ω) |
Rintangan Penebat (MΩ) |
Kuasa |
PH13111 |
13 *111 |
62 |
3600 |
≤20 |
2000 |
25 |
PH13111-1 |
13 *111 |
62 |
3000 |
≤20 |
2000 |
25 |
PH1560 |
15 *60 |
40 |
2600 |
≤20 |
2000 |
30 |
PH1562 |
15 *62 |
40 |
2600 |
≤20 |
2000 |
30 |
PH1547 |
15 *47 |
60 |
2600 |
≤20 |
2000 |
50 |
PH2056 |
20 *56 |
50 |
2500 |
≤20 |
2000 |
30 |
PH2589 |
25 *89 |
28 |
2000 |
≤20 |
2000 |
100 |
PH3090 |
30 *90 |
28 |
5700 |
≤20 |
2000 |
200 |
PH3091 |
30 *91 |
30 |
3500 |
≤20 |
2000 |
200 |
PH40125 |
40 *125 |
20 |
8000 |
≤20 |
2000 |
500 |
PH4090 |
40 *90 |
28 |
10000 |
≤20 |
2000 |
500 |
PH50180 |
50 *180 |
15 |
15000 |
≤20 |
2000 |
700 |
PH50107 |
50 *107 |
20 |
15000 |
≤20 |
2000 |
1000 |
PH50107-1 |
50 *107 |
20 |
9000 |
≤20 |
2000 |
1000 |
PH50120 |
50*120 |
20±2 |
13000±10% |
≤20 |
≥2000 |
2000 |
PH60160 |
60*160 |
15 |
11000 |
≤20 |
2000 |
1500 |
PH50116 |
50.2 *116.9 |
20±1 |
15000±10% |
≤20 |
≥2000 |
1000 |
PH61161 |
61*161.8 |
15±0.5 |
14000±15% |
≤20 |
≥2000 |
2000 |
PH51165 |
51*165.4 |
15±0.5 |
10.2nF±10% |
≤20 |
≥2000 |
2000 |
PH64232 |
64*232 |
20.15 |
9670 |
≤10 |
≥100 |
1250 |
PH64116 |
64*116 |
20 |
14680 |
≤25 |
≥100 |
1050 |
PH80233 |
80*233 |
14.90 |
8000 |
≤10 |
≥100 |
2100 |
Jika transduser ini tidak dapat memenuhi keperluan anda, sila beritahu kami saiz anda, kilang kami boleh menerima penyesuaian.
